Guard-Based Conditional UI Logic in Sparklet: Controlling State Transitions and View Visibility

Modern embedded HMIs—especially in automotive and industrial systems—are no longer simple collections of static screens. They are state-driven, context-aware interfaces that must react correctly to system conditions, user inputs, and safety constraints.

To manage this complexity in a clean and deterministic way, Sparklet UI Designer introduces Guards—a powerful mechanism for controlling UI transitions and view visibility based on well-defined conditions.

This blog explains what Guards are, why they matter, and how Sparklet UI Designer leverages them to build safe, predictable, and scalable embedded user interfaces.

Why Conditional UI Logic Matters in Embedded Systems

In embedded HMIs, incorrect UI behavior is not just a visual issue—it can impact usability, safety, and compliance. Common challenges include:

1. Screens appearing at the wrong time
2. Invalid transitions between UI states
3. Warning views showing when conditions are not met
4. Hardcoded logic scattered across application code

As systems grow more complex, managing UI flow purely through application logic becomes error-prone and difficult to maintain. This is where Guard-based UI logic becomes essential.

What Is a Guard?

At its core, a Guard is a conditional check—a gatekeeper. It is a Boolean function that evaluates the system's runtime state to determine if a specific action is allowed to proceed.

In Sparklet UI Designer, Guards abstract complex logical conditions into reusable components. Instead of writing code like if (speed > 0 && brake_status == false) {return;} inside a button click handler, you define a Guard named isVehicleMoving. You then attach this Guard to UI elements or transitions. If the Guard evaluates to false, the action is blocked, or the element remains hidden.

This separation of concerns is essential for predictability. The UI logic becomes declarative ("Show this if Safe") rather than imperative ("Check safety, then draw").

Guards in State Machines: Protecting Transitions

State machines are the backbone of robust embedded HMIs, defining exactly which screens (states) exist and how the user moves between them. However, a transition shouldn't always happen just because a user tapped a button.

In Sparklet UI Designer, you can attach a Guard to any transition between states.

How it Works

When a trigger event occurs (e.g., a "Settings" button press), Flint checks the associated Guard before initiating the state change.

1. Trigger: User taps "Settings".
2. Guard Check: Flint evaluates isVehicleStopped.
3. Outcome:
   True: The transition proceeds; the HMI moves to the Settings screen.
   False: The transition is blocked; the HMI remains on the current screen (and optionally plays a rejection sound or animation).

Example: The Ignition Interlock

Imagine an automotive cluster. You have a transition from the "Off" state to the "Drive" state.

Trigger: User presses the "Start Engine" button.
Guard: isBrakePressed AND isKeyDetected.

Without these Guards, the UI might transition to the "Drive" dashboard while the engine is actually off—a dangerous desynchronization between the HMI and the vehicle's physical reality.

Beyond Transitions: Guards in Placeholders

While state machine guards are common in many tools, Sparklet UI designer extends this concept powerfully into Placeholders.

A Placeholder in Flint is a dynamic container in the layout that can load different Views (widgets or screens) at runtime. By applying Guards to these Placeholders, you unlock Conditional Visibility and Context-Aware Layouts.

Dynamic View Selection

Instead of hardcoding visibility logic, you can map multiple Views to a single Placeholder, each protected by a Guard. Sparklet UI designer evaluates the list of Guards and renders the first View whose Guard returns true.

This enables complex UI behavior without complex code:

1. Priority 1 (Guard: isCriticalError): Show Red Alert Overlay.
2. Priority 2 (Guard: isWarning): Show Yellow Toast Notification.
3. Priority 3 (Guard: default): Show Nothing (Empty View).

This mechanism ensures that high-priority warnings always supersede normal notifications, purely through configuration.

The Benefits of Guard-Based UI Logic

Adopting Guards in Sparklet UI designer offers immediate, tangible benefits to embedded teams:

1. Enhanced Safety: Critical logic is centralized. You can audit your Guards to ensure no unsafe transitions are possible.
2. Cleaner Architecture: It decouples the conditions (business logic) from the presentation (UI code). Your view code doesn't need to know why it is hidden; it just knows it shouldn't render.
3. Maintainability: Changing a safety rule (e.g., adding a new interlock condition) requires updating the Guard in one place. You don't need to hunt through dozens of UI files to find every if statement.
4. Scalability: As your system grows in complexity, Guards allow you to layer logic without creating a fragile house of cards. You can compose complex conditions from simple, testable Boolean checks.

Conclusion

In the high-stakes world of embedded systems, an HMI cannot simply be "pretty"; it must be correct. Guards in Sparklet UI designer provide the rigorous logical framework necessary to build interfaces that are as safe as they are intuitive. By controlling transitions and managing content visibility through strict conditions, developers can sleep soundly knowing their UI will always reflect the true, safe state of the machine.
